DESCRIPTION

Basic Info.

Model NO.	WLgPV-32B
Standard	IEC60269-6
Rated Voltage	1500V
Fuse Size	14X85mm
Rated Current	1A -32A
Function Class	Gpv
Color	White
Wiring Range	1-10mm2
Transport Package	Export Standard Packing
Specification	300pcs/ctn
Trademark	WZAZURE /OEM
Origin	Zhejiang, China
HS Code	8536100000
Production Capacity	500000pair/Week

Product Description

DC 1P 1500V LED Fuse Holder for Solar PV System Protection Fusible 10x85MM gPV PV Solar Fuse
1. Application
This series of fuse is suitable for solar photovoltaic power generation system,rated voltage to 1500V,rated current to 32A,connected with photovoltaic panels and batteries ,to charge variable flow system for short circuit breaking protection in photovoltaic station and photovoltaic power generation system.the rated breaking capacity is 20KA,products confirms to IEC60269.6
2. Normal Working Conditions Ambient Temperature:-40ºC-+90ºC Equipment installation height:less than 2000m (if you want use exceedng this height,pls tell us in advance,we can design according to your requirements)
3. Use Category gPV means all range DC Fuse used for breaking protection in solar photovoltaic power generation system.
4. Structure Fuse Link is made of pure silver,welding low tin and encapsulated in the high-strength porcelain,the fuse tube filled with high pure quartz sand with chemically processed as a arc medium,fuse body is connected with contacting terminals by spot welding.
5. Technical parameter

Fuse size	10X85MM
Poles	1P
Rated voltage	DC 1500V
Rated current	1-32A
Short-circuit breaking capacity	20KA
Max power attenuation	6.5W
Protection grade	IP20
Operation ambient temperature	-40ºC-+90ºC
Resistance and damp hot	Class 2
keyword	solar fuse base fuses holder dc

Product Display
