DESCRIPTION

Basic Info.

Model NO.	SDC
Transport Package	Pallet
Trademark	Chargepoint
Origin	China
HS Code	8504402000
Production Capacity	100 PCS/Month

Product Description

High Power 200-360kw Single/Double/triple Commercial Split Fast DCEV Charger Model: NKR-SDCOutput Power: 200-360KW Outlet: Double outlets

Specifications

Split DC Modules:

Component	Description
Pilot controller	PC-ADCC-D charging controller + insulation detector
Power module	REG75050/ REG75035, Optional configuration: 24pcs
AC main input power distribution	Main breaker, Main contactor(optional), SPD, 1 ac adapter for maintain, Aux power AC input breaker
DC power distribution	Standard 60KW~480KW system.The positive and negative DC outputs are provided contactors protection and the charger modulehas a built-in discharge circuit.
AC connector distribution	AC connector breaker and contactor, type-B RCD
Temperature control system	Forced air cooling
Net communication	CAN bus

Split DC Charging Terminals:

Component	Description
Pilot controller	PC-ADCC-D charging controller + insulation detector
Upper controller	POC1.6-3352L upper controller
DC Charging gun	200A CCS-2 or 200A CCS-1 / 125A CHAdeMO
AC main input power distribution	Main breaker, Main contactor(optional), SPD, 1 ac adapter for maintain, Aux power AC input breaker
DC power distribution	Standard 30KW~120KW system.The positive and negative DC outputs are provided contactors and fuse protection and the chargermodule has a built-in discharge circuit.
AC connector distribution	AC connector breaker and contactor, type-B RCD
Temperature control system	Closed inner cycle
Card reader	RFID
Metering	2 DC energy meters
HMI	7-inch TFT touch screen display, 5 Panel LED
Net communication	wireless communication (WIFI/4G optional, insert the LTE modem card into Upper controller), 1 LAN,1 CAN bus

AC-DC cabinet (320kw)

Name	NKR-SDC(320kw)
Rated Power	320kw DC output
Input Voltage	3-phase 260-530Vac
Input Current	0-800A(max)
Input frequency	50/60hz
Output Voltage	150-750Vdc
Output Current	0-200A
Material	Sheet metal case
Size	1890*750*910mm(H*W*T)
Weight	570KGS

Charging piles (160kw 2guns )

Name	NKR-SDC (180kw 2guns)
Structure Description	Application scenes	Parking lot/Public charging station
	Size	1800*900*400mm(H*W*T)
	Housing material	Metal case
	Installation method	Floor-stand type
	Cable routing	Bottom inlet wiring,up outlet wiring
	Weight	150kg
	Cable length	5meters
	Charging gun number	2 (CCS2+CCS2)
	Rated power	160kw
	Measuring accuracy	Level 0.5
	Output voltage	150~750Vdc
	Output current	0 ~ 200Adc(limited by cable)
	Efficiency	≥95%
	Power factor	≥0.99
Function design	User Interface	Emergency stop button, LED indicator, card swiping, touchscreen
	Charging standards	IEC 61851-1/IEC 61851-23/-24:2014/ISO15118-1-2013ISO15118-2-2014/ISO 15118-3:2015/IEC 62196-1-2014IEC 62196-3-2014/DIN 70121-2014
	Communication	PLC, CAN, PWM, Ethernet, OCPP 1.6
Environmentcondition	Application place	Indoor/Outdoor
	Working temperature	-30 ° C ~ +70 ° C (Output degraded above 50° C )
	Working humidity	5% ~ 95% without condensation
	Altitude	<2000m (for sea level higher than 2000m, it can work butcharging speed will be lower according to the battery).
	Protection grade	IP54/IK10
	Cooling	Forced-air cooling
	MTBF	100,000 hours
	Safety standard	EN 61851-1-2001; EN 61851-21-2001; EN61851-22-2001
	Security design	Over/under voltage protection, overload protection, currentleakage protection, grounding protection, over temp protection,lightening surge protection

1. Have high voltage charging gun of European standard, American standard and Japanese standard. It can generate different charging configures according to customers' requirements.
2. Modular design, adapt to customers' needs.
3. OCPP communication protocol
4. Have open, shareable data service platform and management platform (cloud platform)
5. Have protection functions such as input under voltage, input overvoltage, output short-circuit, output overvoltage, output overcurrent, battery reverse connection, insulation detection, communication failure, etc.
6. Have an external running indication, which can display the real-time status.
7. Wide range of AC output voltage, high suitability of utility grid, three phase three wire input without null line in the rectifier unit.
8. Has the function of protocol self-recognition, can realize the charging for electric vehicles without limitation of brand.
9. Compatible with coaches and cars charging function.
10. One pile can charge multiple vehicles, and take turns to charge automatically by applying automatic switch function between charging according to the charging power and according to time. It can automatically judge whether the battery is full, one charging pile can meet at least five vehicles charging service task one night.
11. Emergency protection and alarming function, including over voltage, under voltage, over current, over temperature, phase missing, output short-circuit, leakage protection and so on.
12. Charging protection function, the charging process will suspend immediately when BMS communication faults, disconnection, over temperature and over voltage occur.
13. Emergency stop function, the charging process can be suspended immediately by emergency stop switch.
14. Has multiple communication interface such as CAN,RS485/ RS232,Ethernet, 3G wireless networks, which can achieve communication among AC input unit, charging module and DC charging terminal interface, obtain electric vehicle battery system parameters and battery operation parameters during charging process.
15. Has insulation monitoring function, automatically turns off the output to ensure safe charging when insulation level is low.
16. High efficiency, high reliability, ultralow radiation, fast maintenance, flexible capacity expansion, energy efficiency and environmental protection
17. High adaptability of temperature range, has isolated heat dissipation air ducts. Power heat dispassion is separated from control circuit to ensure dust-free of control circuit.
18. Metal closed shell, to prevent from fire.
19. Have display interface which can be customized
